can be found on the seat depth plate. (Fig. 23) Pull the seat depth plate out as far as
possible. Now you can adjust the position of the crotch strap. Please ensure that it is
threaded correctly, refer to the illustration on the seat depth plate.
Crotch strap position for small users (Fig. 25)
Crotch strap position for taller users (Fig. 26)
Now set the desired seat depth again and tighten the two screws again. Thread the
harness buckle through the seat pad and then through the harness buckle pad. Finally,
thread the lower end of the harness shield 5pad through the seat pad in the same way
as the crotch strap. The lower sides of the harness shield pad are now underneath the
seat cushion (Fig. 27).
Basin guide setting
The two pelvic guides provide support and positioning in the pelvic area. They can be
adjusted independently of each other.
Lift the seat cushion at the back to gain access to the pelvic guide screw connection.
(Fig. 28) Loosen the screw connection with an Allen key (from below) and an open-
ended spanner (on the seat plate). (Fig. 28 + 29)
Set the desired width and tighten the screws again.
The seat cushion can simply be put back again.
Leg guide setting
The two leg guides provide support and positioning in the thigh area. They can be
adjusted independently of each other.
The screw connection is located underneath the seat plate. If the seat depth is set to
the smallest position, the seat depth must first be pulled out in order to gain access to
the screw connection of the leg guide. If the seat depth is not set in the smallest posi-
tion, there is direct access to the screw connection below the seat plate.
Loosen the screw connection with an Allen key and adjust the width as desired. Now
tighten the screws again. Check that the seat cushion is correctly seated.
Adjustment 5-point positioning belt
Please note: The 5-point positioning belt is used to position the user in the seat and
does not protect him/her in the event of an accident. The 3-point safety belt provided
in the car must always be used to secure the user in the seat.
