Upholstery and webbing
Back cushion
The "back" cushion set consists of 4 parts. (Fig. 35)
A = head cushion
B = head cushion
C = 2 x pads folding joint
D = 2 x pads Side impact protection

Seat cushion

The "seat" upholstery set consists of 4 parts. (Fig. 36)
E = seat cushion
F = 2 x pelvic cushion
G = 2 x leg guide
H = Seat belt shield pad
Seat belt
Set of harnesses (Fig. 37)
J = 5-point positioning belt
K = 2 x shoulder strap pads

Accessories

Note: The assembly / disassembly of the accessories is done with standard tools.
• Allen key size 4 + 5 and open-end spanner size 10 + 13 (back plates)
• Allen key size 3 + 4 and open-end spanner size 8 + 10 (seat plates)
• Screw lock (Loctite®)
• Hair dryer (for loosening screwed connections where the screw lock
has been used
You can also find detailed assembly instructions in videos on the Internet:
http://www.thomashilfen.de/hercules-small-montage
