Gebrauchsanweisung – Hercules Small
Instructions for Use – Hercules Small

Setting options / performance features

Wrinkles
Hercules Small can be folded for easy, space-saving transport.
Unfold
Release the red eccentric levers on both sides of the seat to unfold the seat. (Fig. 10)
Then secure the seat in the desired position. The seat must be leaning against the car
seat.
The pads for the folding joint are attached to the back plate with Velcro for transport
and placed behind the back pad. (Fig. 11) Pull out the poster for the folding joint. Posi-
tion the pads over the folding joint. The green belt marking must be over the indenta-
tion in the folding joint. (Fig. 12). Fix the pads to the outside and inside of the sheet
metal with Velcro. (Fig. 13)
Fold
First loosen the two pelvic pads on the left and right on the outside (Fig.14) and place
them behind the backrest padding. (Fig. 11) This prevents the cushions from being
squeezed when folded. Then loosen the two red eccentric levers on both sides of the
seat. Now fold the seat and secure it in the folded position.

Back height adjustment

Determine the user's back height (from the seat to the top of the head).
Loosen the backrest cushion at the top of the backrest plate (Fig. 15). Pull the backrest
upholstery forwards. In doing so, the backrest upholstery can be pulled out of the
shoulder straps of the 5-point positioning belt (Fig. 16). Now the backrest upholstery
can be placed on the seat surface. The screw connection of the back plates is now
easily accessible.
Use an open-ended spanner to loosen the four screws until the back plate can be
moved. (Fig. 17)
The scale on the back of the back plates helps you to find the right setting. (Fig. 5)
Then fix the four nuts of the back plates at the required back height. (Fig.15)
Adjust the available length of the backrest cushion. To do this, loosen the lower end
of the backrest cushion under the seat cushion and pull it out. The remaining length is
reattached to the Velcro strap under the seat cushion. (Fig. 18)
Pull the backrest upholstery back over the backrest plate (Fig. 15) Make sure that the
51
2023-07
