shoulder straps of the 5-point positioning belt are again in front of the backrest uphol-
stery and are not twisted. (Fig. 19)
Check the correct routing of the 3-point seat belt while driving. The red belt guide
with the vehicle's 3-point safety belt must always be above the user's shoulder. (Fig.
20)
Back angle adjustment
Use the red eccentric levers on both sides of the Hercules Small to to adapt the back
of the seat to the backrest of the vehicle seat. (Fig. 10)
Make sure that the positioning seat is in full contact with the backrest of the vehicle
seat.

Headrest adjustment

The headrest is used to support and position the head and provides optimal protec-
tion for the user. The two sides can be adjusted independently in height and width.
Loosen the backrest upholstery at the top of the backrest plate to gain access to the
screw connection of the headrest (Fig. 15).
Loosen the screw connection with an open-ended spanner. Adjust the position of the
headrest to the user and fix the screw connection again. (Fig. 21)
Pull the back cushion over the top of the back plate.

Seat depth adjustment

Determine the required seat depth (backrest to the back of the knee)
The seat depth screw connection is located on the underside of the seat. Place the
seat outside the vehicle on the back plate to gain access from below.
to the seat. Lift the seat cushion to gain access to the nuts on the seat. Use an Allen
key (underneath the seat) and an open-ended spanner (on the seat plate) to loosen the
screw connection of the seat depth adjustment. (Fig. 22 + 23) Move the upper seat
plate to the desired depth. Then retighten both screws and position the seat cushion
on the seat plate.
Crotch strap adjustment
Tip: Change the setting outside the vehicle to have enough space.
The crotch strap can be used in two positions on the seat plate. Loosen the belt
fastener and remove the harness shield pad and the seat pad from the seat plate. (Fig.
25) Place the Hercules Small preferably on the back plate and loosen the seat depth
screw connection. The two screws can be reached from below. (Fig. 22) The nuts
