Gurtführung / Belt guide
2023-07
max.
50 kg /
110.2 lbs
Gebrauchsanweisung – Hercules Small Instructions for Use – Hercules Prime
Belt guide 5-point belt
Position on the product (Fig. 3)
Reference to the belt guide:
• Shoulder straps (back plate
above)
• Lap belts (back plate below)
• Crotch strap (seat plate)
• Driving direction / belt routing
• 3-point safety belt (Fig. 4)
• Scale back height
• For easy adjustment of the back
height. (Fig. 5)
