29. Align the bottom door hinge (N) to the prepared holes on the left side of the
appliance properly and screw it tightly using the self-tapping screws (P); s. fig.
below.
30. Align the foot support of the front foot (O) to the prepared holes on the right
side of the appliance properly and screw it tightly using the self-tapping screws
(P); s. fig. below.
31. Screw the adjustable supporting feet (M) back again (s. fig. below).
M
N
O
P
32. Attach the freezer door to the bottom door hinge. For this purpose, insert the
hinge axis of the bottom door hinge into the bottom hinge hole of the freezer
door carefully. Hold the door in position (s. fig. below).
A
DJUSTABLE SUPPORTING FEET
B
OTTOM DOOR HINGE
F
OOT SUPPORT OF THE FRONT FOOT
S -
ELF TAPPING SCREWS
