24. It is necessary to tilt the appliance backwards. Lean the appliance against a solid
and immovable surface so it will not slip. Do not tilt the appliance more than
45 0 .
25. Unscrew the adjustable supporting feet (M); s. fig. below.
26. Unscrew the self-tapping screws (P) of the bottom door hinge (N) and remove
it (s. fig. below).
27. Unscrew the self-tapping screws (P) of the foot support of the front foot (O)
and remove it (s. fig below).
M
N
O
P
28. Unscrew the hinge axis (Q) of the bottom door hinge (N) and install it in the
adjacent opening (R). Install the washer (S); s. fig. below.
The washer (S) may stick to the door.
NOTICE! Pay attention to the washer of the bottom door hinge. The
washer may stick to the door. Do not lose the washer.
A
DJUSTABLE SUPPORTING FEET
B
OTTOM DOOR HINGE
F
OOT SUPPORT OF THE FRONT FOOT
S -
ELF TAPPING SCREWS
