Instructions for installation and use

3. Product description

3.1. Scope of delivery

● Sauna control unit
● Heater sensor with integrated excess temperature fuse
● Installation material
● Wire jumper for bridging terminals V1 and Wm for combi heaters without
low-water shut-off

3.2. Optional accessories

● Bench sensor (item number: O-F2), sensor wires 1.5 m
● Humidity temperature sensor (item number: O-FTS2), sensor wires 3 m
● Foil sensor (item number: P-ISX-FF), sensor wires 3 m
● Power booster (item number: O-S2-18 / O-S2-30)
● Safety shut-off (item number: HT-SWL)
● pronet web server (item number: PRO-NET)

3.3. Product functions

The sauna control unit Pro C3 features the following functions:
● Regulation of combi heaters with a heating output of up to 10.5 kW and
evaporator output of up to 3.5 kW in the temperature range spanning 30 °C
to 110 °C and a humidity range spanning 5 % to 100 %.
● A power booster allows the maximum contact rating to be increased from
10.5 kW to 18 kW or 30 kW.
● Optional dimming or activation of a room light (up to 100 W)
● Optional dimmer function or activation of a fan (up to 100 W)
● Remote start function
