Tabella configurazione DIP-SWITCH

Oltre ai parametri inseribili da pannel-
lo, le unità sono dotate di una serie di
dip-switch, tramite i quali gestire alcune
opzioni e funzionalità della macchina.
Si ricorda che alcune delle opzioni
gestibili dal pannello sono vincolate
ad uno specifi co settaggio di alcuni
dip-switch.
Configuraciones por defecto DIP-SWITCH MODUCONTROL
Unidades
1 2
ANL OFF OFF
ANL H ON OFF
ANL C ON OFF
ANL A/Q ON OFF
ANL HA/HQ ON OFF
ANL Z/Y ON OFF
ANLI H ON OFF
ANR H ON OFF
ANR HA/HK ON OFF
ANR HP ON OFF
ANF H ON ON
ANF HA/HK/
ON ON
HJ
ANF HP ON ON
ANK ON ON
ANK Z/Y ON ON
ANK A ON ON
SRP ON ON
176
ES
IMDCFJ. 12.05 6343841_03
Dip-switch (B)
DIP-SWITCH (A)
3 4 5 6
OFF OFF ON OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF ON ON ON
OFF ON OFF ON
ON OFF OFF OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF ON OFF ON
OFF OFF OFF OFF
OFF OFF ON OFF
OFF ON ON ON
OFF OFF ON OFF
OFF OFF ON OFF
ON OFF OFF OFF
OFF ON ON ON
OFF ON ON OFF
7 8 9 10
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF OFF ON OFF
OFF OFF OFF OFF
OFF ON OFF OFF
ON OFF OFF OFF
OFF ON OFF OFF
OFF ON OFF OFF
ON ON OFF OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF ON OFF OFF
Dip-switch (A)
DIP-SWITCH (B)
11 12 1
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- ON OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
