CONTROL ELEMENTS / DISPLAY INDICATIONS
9
5

Control elements

■
1) " " Key:
2) " " Key:
3) " " Key:
4) " " Key:
5) " " Key:
6) " " Key:
7) " " Key:
8) " " Key:
9) " " Key:
10) " " Key: programs setting or advanced programming
11) " " Key:
12) " " Key:
13) " " Key:
12
11
2
10
manual operation
increases the selected field or displays the daily maximum
temperature
decreases the selected field or displays the daily minimum
temperature
confirms the set data
activation and deactivation of the programmable thermostat
selects temperature T3
selects temperature T2
selects temperature T1
allows to set a timer or an activation delay
clock setting
winter operation (preset) or summer operation (the button is
reachable only with a point)
deletes date and time but not the set programs (to do this see
"Restoring default parameters" page 56)
(the key is reachable only with a point).
ORUS RF Programmable Thermostat User Manual
13
3
1
- 37 -
8 7
4 6
