Expanding the system through stacking
In Stacking mode, you can switch multiple matrix switches at the same time.
For this, connect the matrix switches via
bus addresses.
Each stacking matrix switch consists of a matrix switch that provides the
. You can add up to 9 satellite matrix switches to the matrix switch. The sat-
Channel
ellites can be used either as
IMPORTANT:
Within a channel, you can only use compatible target and user
modules:
Video Follower Channel:
USB/RS232 Main Channel:
U2-CPU series
NOTE:
Connect the user modules of one console to the same port numbers of the
different channels.
The same applies for the different target modules of one computer.
When using three matrix switches, for example, you can transmit a second video
signal and USB 2.0 signals in addition to the standard signals of a user module
(video signal and keyboard and mouse signals):
Matrix switch
Matrix switch 1 (Primary)
Matrix switch 2 (Satellite 1)
Matrix switch 3 (Satellite 2)
Connecting a stack matrix switch
A stack matrix switch is a matrix switch that transmits additional signals of a com-
puter or a console.
A stack matrix switch is not switched by users, but by the primary matrix switch. If
the user accesses a port at the primary matrix switch, the port is also accessed at the
stack matrix switches.
You can include up to ten matrix switches(1 × primary, 9 × satellites) in a stack cas-
cade.
Bus
Video Follower Channel
User and target modules of the DVI-CON or DVI-CPU series
User and target modules of the U2-CON or
User module
DVI-CON
DVI-CON-Video
U2-R-CON
Expanding switchable signals
ports and assign them with continuous
or as
USB/RS232 Main Channel
Signals
DVI, PS/2, USB
DVI
USB 2.0, RS 232
