Installation

Installation
NOTE:
The following drawings refer to the
variants vary in the number of dynamic ports to connect user modules and target
modules.
The following pages describe the installation of the devices of the KVM system.
NOTE: When choosing a place for the device, please ensure to comply with the
ambient temperature limit (see Technical data on page 27) close to the device. The
ambient temperature limit must not be influenced by other devices.

Power supply

18 20 22 24
17 19 21 23
Plug one of the supplied power cable in this interface. Connect the
Main Power:
power cable with a power outlet and turn the power button on.
Red. Power: If required, plug one of the supplied power cable in this interface to
establish a redundant power supply. Connect the power cable with a power outlet of
another power circuit and turn the power button on.
4 · G&D ControlCenter-Compact
26 28 30 32
25 27 29 31
ControlCenter-Compact-32C
Bus In
Power
Red.
Main
Status Ident.
Bus Out
Portfunction
Fail
. The different
Main Power Red. Power
