The »ControlCenter-Compact« KVM matrix system
The »ControlCenter-Compact«
KVM matrix system
KVM matrix systems of the ControlCenter-Compact series consist of at least one cen-
tral module, one user module and one target module.
The central module of the ControlCenter-Compact series is the central device of the
KVM matrix system. Both target and user modules are connected to the central
module.
You can use the KVM matrix system to access a target module with a user module.
By accessing the computer connected to the target module, the video image is dis-
played at the console monitor. You can now operate the accessed computer with
console keyboard and console mouse.
The ControlCenter-Compact series includes the following variants:
Variant
ControlCenter-Compact-16C
ControlCenter-Compact-32C
ControlCenter-Compact-48C
ControlCenter-Compact-64C
ControlCenter-Compact-80C
Use the dynamic ports to connect either user modules or target modules.

Expanding a KVM matrix system

If the number of ports of a matrix switch is not sufficient for the desired purpose,
you can combine multiple matrix switches.
For this, we provide the technologies
ject to a charge).
Information about these technologies is given in the chapter Expanding the KVM
matrix system by cascading on page 15.
2 · G&D ControlCenter-Compact
Dynamic ports to connect modules
16 × RJ45 socket (CAT)
32 × RJ45 socket (CAT)
48 × RJ45 socket (CAT)
64 × RJ45 socket (CAT)
80 × RJ45 socket (CAT)
(default) and
Cascading
(sub-
KVM Matrix-Grid™
