Spare Parts Kits; Order Data - Gemü R690 Originalmontageanleitung

Key
Item Components
3 Compressor
4 Lip ring
5 Lock washer
6 Membrane plate
9 Washer
10 Actuator top
12 Bolt
13 Washer
14 Actuator membrane
15 Actuator spindle
16 Actuator base
17 Bush
21 Hexagon nut
22 Sealing washer
27 O-ring (only for diaphragm sizes 40 and 50)
Distance piece
28
(only for diaphragm sizes 40 and 50)
29 Protective cap
30 Dowel pin
31 Adapter
47 Washer
FP Spring set
SA1 Optical position indicator
SA2 Protective cap

3 Spare parts kits

3.1 Spare parts kit SAF
Item Pieces Components
IF 1 Compression spring
MF 1 Compression spring
AF 1 Compression spring
R690
3.2 Spare parts kit SAK
Item Pieces Components
4 1 Lip ring
5 1 Lock washer
14 1 Actuator membrane
Bush
17 1
(for diaphragm size 50: 2 bushes)
21 1 Hexagon nut
22 2 Sealing washer
O-ring
27 1
(only for diaphragm sizes 40 and 50)

4 Order data

4.1 Order data - Spare parts kit SAF
1 Type
GEMÜ R690
2 Diaphragm size
Diaphragm size 25 (DN 15 / DN 20 / DN 25)
Diaphragm size 40 (DN 32 / DN 40)
Diaphragm size 50 (DN 50)
3 Kit
Compression spring spare parts kit
4 Control function
Normally closed (NC)
5 Actuator size
10 bar operating pressure:
Diaphragm size 25 (DN 15 / DN 20 / DN 25)
Diaphragm size 40 (DN 32 / DN 40)
Diaphragm size 50 (DN 50)
6 bar operating pressure:
Diaphragm size 25 (DN 15 / DN 20 / DN 25)
Diaphragm size 40 (DN 32 / DN 40)
Diaphragm size 50 (DN 50)
6 K number (optional)
Medium wetted area cleaned to ensure suitability for
paint applications, parts sealed in plastic bag, warranty
only valid when treated with proper care!
Order example
1 (Code)
2 (Code)
3 (Code)
4 (Code)
5 (Code)
6 (Code)
8 / 12
R690 25 SAF 1 FDN 0101
R690
25
SAF
1
FDN
Code
R690
Code
25
40
50
Code
SAF
Code
1
Code
FDN
HDN
KDN
FDM
HDM
KDM
Code
0101
0101
