1. Description

The EX-61004 is a multiprotocol RS-232/422/485 serial device server for integrating RS-
232/422/485 serial devices, such as barcode scanners, weighing systems and payment terminals,
into an IP-based Ethernet network. The serial devices are connected to the network and are
available for sharing on the subnet and the Internet. Extensive network protocols such as TCP
Server, TCP Client, UDP, VCOM, Remote Pair Master Slave, Modbus Server, Modbus Client and
SNMP are supported. In addition, serial devices with remote pair master-slave mode can
communicate with each other via peer-to-peer mode without the need for an intermediate PC or
conversion software. With the Virtual COM (VCOM) software available for download, a perfectly
migrated virtual serial port can be created on Windows computers for each serial device.
Features:
4x RS-232/422/485 port via RJ45 Ethernet 10/100Mbps
Up to 921.6 Kbps baud rate
Serial modes:
Ethernet protocols:
Operating modes:
Configuration: Windows-based VCOM administrator utility and web browser
Certificate for

2. Extent of delivery

Before you integrate the EX-61004 into your network, you should first check the contents of the
delivery:
EX-61004
4x RJ45 to DB9 adapter cable 20 cm
Power Supply (12V/1A)
Wall mounting brackets
Quick Start Guide
© Copyright 2023 by EXSYS Vertriebs GmbH. All rights reserved
RS-232, RS-422, RS-485 2-wire
ARP, IP, ICMP, UDP, TCP, HTTP, DHCP, SNMP, MQTT, MODBUS
VCOM, MCP, TCP Server, TCP Client, UDP, Remote Pair mode,
Modbus TCP Server, Modbus TCP Client
16
EX-61004
