26 | English
Technical Data
Article number
Input voltage
Maximum input current
Input frequency
Direct current output
– Output voltage
– Maximum output current
Storage temperature
Operating temperature
Relative humidity
Data interface
Maximum transmission range
Backup batteries
Weight according to
EPTA-Procedure 01:2014
Protection class
Degree of protection
®
Bluetooth is a registered trademark of Bluetooth SIG, Inc. (Special Interest Group).
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
* The transmission range can be influenced by ambient conditions. Walls made of or containing metal will reduce the transmission range.
Assembly
Operating and Storage Environment
The access point and the I/O module are suitable exclusively
for commercial operation at enclosed work sites. For trouble-
free operation, the permitted ambient temperature should lie
between 5 °C and 70 °C (41 °F and 158 °F) at a permitted
relative humidity of between 20 and 90%, free of condensa-
tion.
System Requirement
The EXAConnecT access point and the I/O module are sup-
plied without a cable and must be properly wired before being
put into operation.
For data retrieval you will also need a PC with the following
software:
– Microsoft Windows XP, Vista, 7 or 8 (32 and 64 Bit) op-
erating system
– Up-to-date web browser which supports Java Runtime
Environment (JRE) from version 1.4
– Java Runtime Environment (JRE) from version 1.4
1 609 92A 43G | (5.10.17)
EXAConnecT access point
0 602 491 003
V 100–240
mA 150
Hz 50–60
V
mA 200
°C -20 ... 80
°C 5–70
20–90,
% free of moisture condensation
Bluetooth wireless technology class 2
(specification 1.2)
RS422 (2x serial)
RS232
Ethernet (1x)
m 10,0*
1,5 V (Standard microcell AAA)
Button cell
(3 V lithium battery, CR 2032)
kg 0,91
IP 54
(dust and splash water protected)
Connections of the access point
Configuration of your PC/system is not explained in these op-
erating instructions. For connecting devices such as the re-
lease button or barcode scanner, you will also only receive in-
structions concerning the access point.
Connection Work (see figure A)
Due to the complexity of the electrical cir-
cuitry, the EXAConnecT access point and
the external devices must be connected
only by personnel trained in electrical engineering and in-
formation technology. Otherwise the safety of the user and
the devices is not ensured.
 DANGER! Ensure that the access point and the I/O mod-
ule are not connected to the power supply before you
open them. The access point must be completely de-ener-
gised, otherwise there is a risk of electric shock.
The terminal strip 18 for connecting the external modules is
located under the maintenance cover plate 8.
I/O module expansion module
0 602 491 004
24
200
24
-20 ... 80
5–70
20–90,
free of moisture condensation
RS422 (2x serial)
Ethernet
(1x; with 2 connection possibilities)
0,51
/I
IP 54
(dust and splash water protected)
