E N G L I S H
Using an extension cable
If an extension cable is required, use an approved
extension cable suitable for the power input of this
tool (see technical data). The minimum conductor
2
size is 1.5 mm
. When using a cable reel, always
unwind the cable completely.
Also refer to the table below.
2
Conductor size (mm
)
0.75
1.00
1.50
2.50
4.00
Voltage
Amperes
115
0 - 2.0
2.1 - 3.4
3.5 - 5.0
5.1 - 7.0
7.1 - 12.0
12.1 - 20.0
230
0 - 2.0
2.1 - 3.4
3.5 - 5.0
5.1 - 7.0
7.1 - 12.0
12.1 - 20.0
Assembly and adjustment
Prior to assembly and adjustment always
unplug the tool.
Fitting sanding sheets (fig. B)
• Fit the sanding sheets using both clamps (2) on
the sanding base (6).
• Quick-fix sanding sheets can be attached directly
to the special sanding base.
Perforating sanding sheets (fig. C)
Your orbital sander uses perforated abrasive.
A hole perforation jig (5) is available as an option to
punch unperforated abrasive.
en - 4
Cable rating (Amperes)
6
10
15
20
25
Cable length (m)
7.5
15
25
30
45
Cable rating (Amperes)
6
6
6
6
6
6
6
6
15
6
6
10
15
20
10
10
15
20
20
15
15
20
25
25
20
20
25
-
6
6
6
6
6
6
6
6
6
6
6
6
10
10
10
10
10
15
15
15
15
15
20
20
20
20
20
25
Proceed as follows:
• Fit the sanding sheet to the sanding base (6).
See also fig. B.
• Press the jig (5) and the sanding base (6)
together. Make sure that the jig guides (5.1) are
located against the corners of the sanding base.
Fitting the brush frame with the extractor hood
(DW634, option) (fig. D)
The use of the brush frame and extractor hood is
recommended for very fine finish sanding operations
(e.g. on high-grade veneers and marquetry work),
for sanding filler, for sanding down lacquer or paint,
coarse sanding and for brushing out pores prior to
lacquering.
60
Proceed as follows:
• Push both parts of the extractor hood (4) onto
6
10
the machine base and secure them by means of
15
the six fixing bolts (10) at the side and the top.
20
• Place the bosses (3.1) at the front of the brush
25
frame (3) in the notches (4.1) of the extractor
-
hood (4). Attach the brush frame to the rear of
-
-
the extractor hood (4.2) by pressing the brush
6
6
frame until the locking pins (3.2) snap in position.
6
6
15
Instructions for use
15
20
-
Sanding (fig. E)
• Press the ON/OFF-switch (1).
• If necessary, press the lock-on button (11) for
continuous operation.
• Make sure all materials to be sanded are well
secured.
• Apply only a gentle pressure to the workpiece.
Excessive pressure does not improve the sanding
effect, but only results in an increased load on
the machine and causes the abrasive to tear.
• To stop the tool in continuous operation, press
the ON/OFF-switch (1) briefly and release it
immediately. Always switch OFF the tool when
work is finished and before unplugging.
Always observe the safety instructions
and applicable regulations.
Fire hazard! Do not use the sander on
magnesium.
15
