26. TECHNICAL DATA SHEET

Intended operator
Channels
Programmes
Battery
output voltage and intensity
actiTENS
Essential performance of the
AC charger input voltage and intensity
Frequency of supply network
Input and output voltage and intensity of
the
actiCHARGE
Conditions of use of the actiTENS, the
charging case and the AC
actiCHARGE
charger
Charging conditions of the
standard kit storage conditions
actiTENS
storage conditions
actiTENS
charging case storage
actiCHARGE
conditions
AC charger storage conditions
Warm-up time of the device when it has
been stored at -10°C for it to be ready for
use at ambient temperature (20°C)
90

TECHNICAL SPECIFICATIONS

actiTENS
charging case
actiTENS
Final users (patients), caregivers or expert users.
All users must be persons over 18 years of age with
unimpaired intellectual abilities.
2 independent channels
14 programmes including:
ƒ Gate control: 80-100 Hz, pulse width 150-200 µs
ƒ Endorphinic: 2 Hz, pulse width 250 µs
ƒ Mixed programmes
ƒ EMS programme (electrical muscle stimulation)
Current delivered: from 1 mA to 60 mA ± 10%
(1000 Ω) in steps of 0.5 mA
Li-ion
max 60 mA ± 10% (1000 Ω) / max 60 V ± 10%
Does not deliver a current 60 mA ± 10% or a voltage > 60 V ± 10%
100-240 V AC 0.1-0.2 A
50-60 Hz
5 V DC – 1 A
From 10°C to 40°C with relative humidity from 15%
to 93%
Atmospheric pressure from 700 hPa to 1060 hPa
Ambient temperature
From 5°C to 35°C with relative humidity from 30 %
to 80 %
Temperature between 15°C and 25°C are best suited
to preserve the battery's capacity
From -10°C to 45°C with max. relative humidity of 93%
Temperature between 15°C and 25°C are best suited
to preserve the battery's capacity
From -20°C to 60°C
From -40°C to 85°C
5 minutes minimum
