Torque for screws and bolts
ChillPAC Products (ChillPAC, DualPAC, HeatPAC & LP ChillPAC)
ChillPAC 108
Unless otherwise stated, the following torque table can be used:
Metric standard torque (ISO 8.8)
M
4
5
6
8
10
Nm
2.7
5.2
9.2
22
40
Lubrication during assembly:
Joints with flat gaskets (except spiral wound gaskets):
- Joints with gaskets must always be cross-tightened.
- Lightly oil the mating metallic surfaces at the joint with compressor oil.
- Do not lubricate the gasket itself; oil on the mating surfaces is sufficient.
Joints with O-rings:
- Lightly oil the O-ring before inserting into groove with compressor oil.
- Alternatively apply Extreme TT-42 NLGI 2 (or compatible) grease to the groove before inserting the O-ring.
Fastners (threads):
- For black steel bolts lightly oil with compressor oil.
- For stainless steel threads apply suitable grease with EP additives.
NOTE: For spiral wound gaskets do not apply any oil or grease neither to the mating surfaces nor the gasket itself!
NB: Mark all bolts when tightened with torque with a white pen.
ChillPAC/, HeatPAC & LP ChillPAC
HeatPAC Reciever
ChillPAC, DualPAC, HeatPAC & LP ChillPAC
Rev. by: CPB
Date: 7. Jun. 2022
Instruction number: 0171.1001
TSJ
12
14
16
18
20
69
108
147
225
295
Gasket and O-rings
Level switch - Oilpot
G3/4" ISO228
316L
41 Nm
Part no.
3445.508
Danfoss EVRA 25
Screw
M14
75 Nm
-
Part no.
Variant
NB. Several variants of M14 screws
Same torque for all EVRA 25 flange
Level sensor - AKS4100
AKS4100
G1" ISO228
316L
120 Nm
Part nr.
3185.290
Valve
10 mm
Ø10 - G1/4"
20 Nm
Sight glass HeatPAC Receiver
Screw
M8 x 30
OD= 39.5 mm.
Kv. 8.8
22 Nm
Part no.
1424.190
Rev. 1 (See change description in TDV/ Excel vers.)
22
24
27
375
510
670
DualPAC GHUR
Dowty ring
Ø 34.93/27.05x2.34 mm.
NBR
-
Part no.
1331.433
Gasket ring
Ø 39/29x2 mm.
Compr fiber
-
Part no.
2356.258
Motor bracket
Gasket ring
40.5/33x1.5 mm.
Alloy 1200
-
Part nr.
2356.144
Valve NDL
BSPP Port
-
-
35 Nm
-
Glass
Gasket ring
39/31x1.5 mm.
THD 60 bar
C4400
-
-
Part no.
Part no.
1226.008
2356.1022
Evaporator ESRE/ ECRE
Sight glass - GHUR
Screw
Glass
Gasket ring
M10 x 60
Ø 63x15 mm. Ø 63/48x1.5 mm.
A2-70
THD 40 bar
C4400
30 Nm
Borosilicate
-
Part no.
Part no.
Part no.
1424.1016
1226.028
2356.319
Motor bracket to baseframe
Screw
M16 x 45 CS
Kv. 10.9
225 Nm
Part no.
6185403
Motor to motor bracket
Max torque 225 Nm
Sight glass - ESRE/ ECRE
Screw
Glass
M10 x 20
OD= 90 mm.
Kv. 8.8
FLG 30 bar
40 Nm
-
Part no.
Part no.
1424.190
1226.008
Optional - Level switch - Liquiphant FTL51
Liquiphant
Gasket ring
G1" ISO228
Ø 40.5/33x1.5 mm
316L
Alloy 1200
120 Nm
-
Part no.
Part no.
1553.302
2356.144
Optional - Level switch - Danfoss LLS 4000
LLS 4000
G3/4" ISO228
316L
10 Nm + 45 degrees
Part no.
1553.302
O-ring
AS568A
Ø 53.0x4.0
HNBR
Part no.
1331-2031
Washer
Ø 45/17x6
350 HV
-
Part no.
1436.098
O-ring
Size 139
Ø 52.07x2.62
HNBR
Part no.
1331.543
Gasket ring
Ø 40.5/33x1.5 mm
Alloy 1200
-
Part no.
2356.140
