Principal Parts - EFFEKTIV TRIUMPHATOR 2500X Benutzerhandbuch

SAVE THESE INSTRUCTIONS
This machine is intended for domestic use only.
This device is not intended for use by persons (including children) with
reduced physical or mental capabilities, or lack of knowledge and skills,
unless they are supervised or trained by a person responsible for their safety.
Supervise children and prevent them from playing with this device.
If the operating conditions and storage rules of the machine are observed,
the service life will be at least 8 years.
RU
6
EN USER MANUAL

PRINCIPAL PARTS

TRIUMPHATOR 2500X
1 . Upper needle-thread tension
2. Upper needle-thread tension
3. Thread tension/ upper looper
thread
4. Thread tension/ lower looper
thread
5. Thread tension/ two-thread
chainstitch looper/ cover
stitch looper
6. Adjusting knob for presser
foot pressure
7. Needle holder
8. Standard presser foot
9. Needle plate
10. Adjusting knob for seam
width
11. Lamp cover
12. Swivel plate
13. Looper disengaging lever
14. Blade guard (for Overedge/
Overlock)
15. Looper cover
16. Presser foot lever
17. Thread chain cutter
