REMOVING THE KNIFE GUARD

RU
36
EN
Remove the trim catcher and
open the front cover.
Pull the knife guard up and off.
То insert, place the knife guard
under latch А and push down into
the front cover guides.
lmportant notes оn sewing with
the top cover stitch sewing tаblе.
The sewing tаblе is marked
with various measurement
units. The figures at the top are
centimeters, those at the bottom
represent inches.
NOTE:
The sewing table (accessory) is
attached in the same way.
USER MANUAL

ADJUSTING THE SEAM WIDTH

TRIUMPHATOR 2500X
Turn the seam width adjustment
knob to select аnу seam width value
from 3.5 to 6.0 mm; it will also Ье
displayed in the viewing window.
(Double chain stitch is sewn with а
gap of 6.5 to 9 mm.)
С
: Seam width adjustment knob
Figure А: lf loops are protruding
from the edge of your seam, turn the
seam width selection knob
upwards to shift the upper knife
to the right. Figure В: lf your seam
puckers at the edge, turn the seam
width selection knob downwards to
shift the upper knife to the left.
