SATEL
10. Start the identification function in the control panel (see the control panel installer
manual). The device will be identified as INT-IT.
Address setting
An individual address (different from that in the other devices connected to the control panel
bus) must be set in the module. Depending on the control panel:
• INTEGRA: set an address in the range from 0 to 31,
• VERSA: set an address in the range from 16 to 21,
To set the address, use the DIP switches on the device electronics board. The switches have
numbers assigned to them. The number for OFF position is 0. The numbers assigned to the
switches in ON position are presented in the table below. The sum of these numbers is the
address set.
Switch (ON position)
Number
The declaration of conformity may be consulted at www.satel.eu/ce
INT-CR
1 2
1 2
3 4
4 8
5
5
16
