Full manual is available on
go to our website and download the manual.
The INT-CR device is used for arming / disarming partitions as well as clearing alarms using
proximity cards. It is supported by the control panels of INTEGRA and VERSA series.
Installation
The device should be installed by qualified personnel.
Changes, modifications or repairs not authorized by the manufacturer shall void
your rights under the warranty.
Disconnect power before making any electrical connections.
The device is designed for indoor installation.
If the device is installed on a metal surface, the card reading range will be reduced.
The distance to another device with a proximity card reader should be at least
50 centimeters.
1. Remove the device cover (Fig. 2).
2. Place the enclosure base on the wall and mark the location of mounting holes.
3. Drill the holes for wall plugs (anchors).
4. Make a hole in the wall for the device cable and run the cable through it.
5. Using wall plugs (anchors) and screws, secure the enclosure base to the wall. Select wall
plugs specifically intended for the mounting surface (different for concrete or brick wall,
different for plaster wall, etc.).
6. Set the device address (see "Address setting").
7. Replace the cover and secure it with the screw.
8. Connect the wires to the control panel screw terminals according to the table below. If the
device cable is too short, you can use an unshielded non-twisted cable to extend it. If you
use the twisted-pair type of cable, remember that CLK (clock) and DTA (data) signals
must not be sent through one twisted pair of wires. The total length of the cable
connecting the device to the control panel should not exceed 1000 meters (INTEGRA) /
600 meters (VERSA). If the distance to the control panel exceeds 300 meters, use
an additional power supply to power the device.
Wire
brown
white
gray
green
9. Power on the alarm system.
Quick installation guide
www.satel.eu.
Function
power
common ground
clock
data
INT-CR
Scan the QR code to
INTEGRA
+EX / +EX1 / +EX2
COM
CK / CK1 / CK2
DT / DT1 / DT2
Terminals
VERSA
AUX / KPD
COM
CLK
DTA
