Installation

Installing and connecting user modules

IMPORTANT: The
technology which comply with laser class 1.
They meet the requirements in accordance to
and
U.S. CFR 1040.10
Mind the following instructions when dealing with laser beams:
 Avoid direct eye exposure to beam on page 4
 Always connect optical connections or cover them with protection caps on page 4
 Only use G&D certified transmission modules on page 4
 Connect the console devices to the different user modules.
The steps required to connect these devices are described in the manual supplied
with the modules:
Manual
DL-DVI-Vision-IP
DL-DVI-Vision-IP-Fiber
DP1.2-Vision-IP
DP1.2-Vision-IP-Fiber
DP-Vision-IP
DP-Vision-IP-Fiber
DVI-Vision-IP
DVI-Vision-IP-Fiber
VisionXS-IP-C-DP-UHR
VisionXS-IP-F-DP-UHR
 Connect the Transmission interfaces of each individual user module to the Gigabit
Ethernet.
