2. Pull the bow handle up.

The dirt receptacle is unlocked and low-
ered.
Illustration D
3. Pull the dirt receptacle out of the device
by the bow handle.
Inserting the dust bag
Illustration E
4. Fit the dust bag in the dirt receptacle and
carefully position it against the container
wall and the container floor.
5. Fold the edge of the dust bag over the
edge of the dirt receptacle to the outside.
Fitting the safety filter bag
Illustration F
6. Fit the safety filter bag.
Illustration G

7. Fold the edge of the safety filter bag out

over the edge of the dirt receptacle.

WARNING
Improper handling when locking the dirt
receptacle

Risk of crushing

Under no circumstances should you hold

your hands between the dirt receptacle and

filter ring or allow them to come close to the
lifting mechanism while locking it.
Lock the dirt receptacle by operating the
bow handle with both hands.
Illustration H
ATTENTION
Static charge of the dirt receptacle
Ignition of dusts
Make sure that the grounding on the chas-
sis is in contact with the dirt receptacle.
8. Fit the dirt receptacle and lock it with the
bow handle.
Removing the dust bag/ safety filter bag
1. Secure the device with the parking
brakes.
2. Remove the suction hose if necessary.

3. Close the suction connection on the dirt

receptacle (see chapter Closing the
suction connection).
Illustration C

4. Pull the bow handle up.

The dirt receptacle is unlocked and low-
ered.
Illustration D
5. Pull the dirt receptacle out of the device
by the bow handle.
Removing the dust bag
Illustration I
6. Turn up the dust bag.

7. Seal the dust bag tightly with the cable

tie.
8. Remove the dust bag.

9. Dispose of the dust bag in accordance

with statutory regulations.

Removing the safety filter bag
Illustration J
10.Fold up the safety filter bag.
Illustration K
11.Peel off the protective film.
12.Close the safety filter bag with the self-

adhesive flap.

13.Pull the safety filter bag out towards the
rear.
Illustration L
14.Seal the suction connection opening of

the safety filter bag tightly with the cover.

Illustration M
15.Close the safety filter bag tightly with the

attached cable tie.

16.Remove the safety filter bag from the

dirt receptacle.

17.Clean the interior of the dirt receptacle

with a moist cloth.

18.Dispose of the used safety filter bag in

dust-tight bag in accordance with statu-

tory regulations.

WARNING
Improper handling when locking the dirt
receptacle
Risk of crushing
Under no circumstances should you hold
your hands between the dirt receptacle and
filter ring or allow them to come close to the
lifting mechanism while locking it.
Lock the dirt receptacle by operating the
bow handle with both hands.
Illustration H
ATTENTION
Static charge of the dirt receptacle
Ignition of dusts
Make sure that the grounding on the chas-
sis is in contact with the dirt receptacle.
