2. Remove the water reservoir.
Illustration H
a Press the lock button down.
b Pull the water reservoir horizontally out of the
cleaning robot.
Installing the wiper cloth
1. Insert the wiper cloth into the slot of the wiper cloth
holder and fix it to the Velcro fastener.
Illustration I
Removing the wiper cloth
1. Press any button.
The cleaning robot stops.
2. Pull the wiper cloth off the Velcro fastener of the wip-
er cloth holder.
Illustration J
Installing the wiper cloth holder
1. Install the wiper cloth holder.
Illustration K
a Press the clamps together.
b Push the wiper cloth holder horizontally into the
cleaning robot until it audibly latches into place.
Removing the wiper cloth holder
1. Press any button.
The cleaning robot stops.
2. Remove the wiper cloth holder.
Illustration L
a Press the clamps together.
b Remove the wiper cloth holder.
Reset WLAN connection
If you switch to a new router or change your WLAN
password, you must reset the cleaning robot's WLAN
connection.
Note
Only 2.4 GHz WLAN networks are supported.
1. Switch on the cleaning robot, see chapter Switching
on the cleaning robot.
2. Press the On/Off button and the "Return to charging
station" button simultaneously for 7 seconds until a
voice says: "Resetting the WLAN connection and
entering network configuration mode".
3. Connect the cleaning robot to the charging station,
see chapter Connecting the cleaning robot with the
charging station.
Restoring the factory settings
 Press and hold the reset button for 3 seconds.
The factory settings are restored
The latest version of the firmware is installed.
 Press and hold the reset button for 10 seconds.
The factory settings are restored.
All network connection information, map informa-
tion, scheduled tasks and do-not-disturb informa-
tion, and customisation information are deleted.
The suction performance is reset to the default val-
ue.
Setting up cleaning zones
The cleaning robot only cleans within the selected area.
Cleaning zones can only be set up with the App. Down-
loading the App is described in the chapter Connecting
cleaning robots with WLAN and App.
 Follow the step-by-step instructions in the App.
Setting up virtual walls
Virtual walls and restricted areas prevent the cleaning
robot from entering areas that should not be cleaned.
Virtual walls can only be set up with the App. Download-
ing the App is described in the chapter Connecting
cleaning robots with WLAN and App.
 Follow the step-by-step instructions in the App.
Activating mapping
The cleaning robot starts from the charging station and
automatically updates its map after completing a clean-
ing task and after charging.
Mapping can only be set up with the App. Downloading
the App is described in the chapter Connecting clean-
ing robots with WLAN and App.
Note
To avoid losing the map, wait a few seconds after the
first mapping until the map is saved.
 Follow the step-by-step instructions in the App.
ATTENTION
Damage due to moisture
Remove the wiper cloth with wiper cloth holder before
charging and when not in use, see chapter Removing
the wiper cloth holder.
Remove the water reservoir before charging and when
not in use, see chapter Removing the water reservoir.
Protect carpets using virtual walls, see chapter Setting
up virtual walls.
Switching on the cleaning robot
Note
Place the cleaning robot directly on the charging station
if it cannot be switched on due to a too low charging
state, see chapter Initial start-up.
1. Keep the On/Off button pressed when the cleaning
robot is in standby and not on the charging station.
The indicator light flashes for approx. 15 seconds
while the cleaning robot starts up and then lights up
constantly.
The cleaning robot emits an acoustic signal when
the start-up is complete.
2. Place the cleaning robot directly on the charging
station.
3. Press the On/Off button.
At initial Start-Up, the cleaning robot starts mapping.
In operation, the cleaning robot starts cleaning.
Setting cleaning modes
Cleaning modes can only be set up with the App. Down-
loading the App is described in the chapter Connecting
cleaning robots with WLAN and App.
The following cleaning modes are available:
● Dry cleaning
● Combination cleaning
● Wet cleaning
The suction power and water quantity can be set in each
of the cleaning modes.
Suction power:
● Quiet
● Standard
● Medium
● Turbo
Water quantity:
● Low
● Medium
● High
