Description; Extent Of Delivery - Exsys EX-1147HMVS Anleitung

EX-1147HMVS

1. Description

The EX-1147HMVS is a USB 3.2 Gen 1 metal HUB for up to seven end devices. The hub is
equipped with 7 ports for end devices and 1 port for connection to PC. It supports all USB ports
from 1.1 to 3.2 and each USB port on the EX-1147HMVS is additionally screwable. Through the
power supply via the Terminal Block or the DC-Connector, 1A can be provided at each USB port.
The USB 3.2 bus optimally supports the performance of the fast Genesys chipset. The EX-
1147HMVS thus ensures secure data transfer and excellent performance of up to 5Gbps. It sup-
ports Self-Powered and USB-Bus-Powered mode. In addition, the EX-1147HMVS is equipped with
15KV ESD surge protection. The EX-1147HMVS supports IP30 standard and comes with a DIN-
Rail kit for installation on a DIN-Rail. The DIN-Rail kit are screwed tight with two screws on the
backside.
Features:
•
Compatible for USB 1.1, 2.0 & 3.2
•
Up to 5Gbit/s
•
All Operating Systems are supported
•
All ports are Screw Lock
•
15KV ESD Surge Protection
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1147HMVS to your PC, you should first check the contents of the deliv-
ery:
•
EX-1147HMVS
•
USB 3.2 Gen 1 Cable (screw lock) (EX-K1591V)
•
DIN-Rail Kit (EX-6096)
•
Manual
© Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved
9
English
