EX-1147HMVS
3. Layout, Connections & Jumper Settings
3.2 Connections
USB 3.2 Gen 1 C-Port:
Note!
By dual assignment of the pins, the USB Type-C plug can be plugged into the port on both
sides.

3.3 Jumper Settings

The EX-1147HMVS will be delivered with the setting USB-Bus-Power.
ity to cut the power at the data line.
sides. Then you must set the jumper JP2 from ENA (Enable) to DIS (Disable).
Attention! Only in connection with JP2 on DIS! Furthermore, you have the option to leave power
on the DFP (Downstream Facing Ports) only when the hub is connected to the host PC and the
host PC is switched on. For this you have to set the jumper JP3 to HOST. If JP3 is set to ON,
there is continuous power on the downstream ports. See the following picture.
JP2
JP3
© Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved
For this you open the case with the four screws on both
DIS
ENA
ON HOST
11
English
But you have the possibil-
