ORIGINAL OPERATING MANUAL
Contents
About this manual............................................ 10
Product description.......................................... 10
Technical data.................................................. 10
Safety instructions............................................11
Installation........................................................ 11
Operation..........................................................12
Maintenance and care..................................... 12
Repair............................................................... 14
Troubleshooting................................................ 14
EC declaration of conformity............................15

ABOUT THIS MANUAL

Please read this document before use. This
is essential for safe working and trouble-free
handling.
Comply with the safety and warning instruc-
tions in this documentation and on the pro-
duct.
This document is a permanent component
of the described product, and should remain
with the machine if it is sold to someone else.

TECHNICAL DATA

Type
Max. load daN (kg) (tensile load)
Lowest cable position
Highest cable position
Gear reduction ratio
Rope *
Minimum breaking force (F min)
Drum capacity (m)
Strap **
Minimum breaking force (F min)
Drum capacity (m)
Pull strap (not permitted for lifting)
Minimum breaking force (F min)
Drum capacity (m)
Minimum load (kg)
Permitted ambient temperature
* according to EN 12385-4 (cable class 6x19 / 6x19 M / 6x19 W - / WRC)
10
Explanation of symbols
CAUTION!
Following these warning instructions can
help to avoid personal injuries and/or da-
mage to property.
ADVICE
Special notes for ease of understanding
and regarding handling.

PRODUCT DESCRIPTION

Cable winches of types:
450 BASIC
900 BASIC
are only to be used to lift, lower and pull the loads
listed in the technical data provided.
Cable winches are not suitable for:
Stages and studios (BGV C1)
Moveable personnel
(BGR 159)
Construction hoists
Motor operation
Continuous operation
Cable winches are not permitted in:
Potentially explosive atmosphere
Corrosive atmosphere
450
450
170
3.5: 1
Ø5 mm
14 kN
15
35-45x2.5
35 kN
3.5 m
48x1
15 kN
6 m
25
- 20° to + 50°C
lifting equipment
900
900
330
8.75: 1
Ø7 mm
27 kN
17
50x2.5
63 kN
5 m
52x1.4
25 kN
7 m
25
