Product description

3.1 Module overview

1
7
No. Designation
1 System interface cover
2 SpO interface
2
3 System interface
4 Locking hooks
5 Module unlocking button
6 Remote alarm interface
7 Mounting holes
2
6
3-1 prisma CHECK module
Description
Covers the system interface if no additional module is
connected.
Used to connect a pulse oximetry sensor.
Used for connection to the therapy device or other modules.
Affix the module to the therapy device or other modules.
Allows connection of the module to the therapy device and
removal of the module from the therapy device.
Used to connect a remote alarm box or an internal hospital
nurse call system. This function cannot be used with
WM 100 TD therapy devices.
Accept locking hooks of other modules.
5
prisma CHECK
3
4
EN 31
