Operation

6 Operation
•
Connect the device (KKV 8/14) as described in "Installation suspension lug" to the lifting device or use it
manual by 2-man operation (at the handles).
•
Move the device (KKV 8/14) in „Transport position" (Fig. 1) to the gripping good.
•
Position the device (KKV 8/14) centric over the gripping good (cable channel) and tilt the handle (a little)
to move the device into the "Operating position" (Fig. 2).
•
The device (KKV 8/14) can now be lifted with the gripping good (cable channel) → see Fig. 3
•
When setting down good gripping at the floor, the device opens automatically (now the device can be
replaced in the "Transport position" again (Fig. 1)).
„Transport position"
Fig. 1
Be careful when changing from transport to operatingposition (and inverse) - risk of injury
to the hands! → Use safety gloves!
53100061
„Operating position"
Fig.. 2
14 / 18
„Device in use"
Fig. 3
