Operation - EuroLite LED PARty Spot COB Bedienungsanleitung

After switching on, the device is ready for operation. The display indicates the last operating mode. The operating
modes can be selected by means of the display and the control buttons. All settings remain stored even if the
device is switching off.
Menu structure
The operating mode is set via the display and the buttons MENU, UP, DOWN and ENTER. Press the MENU button
so many times until the desired operating mode is indicated in the display. Change the values to be set or options
with the UP or DOWN buttons. For modes with adjustable speed, press ENTER to display this option. Details of the
individual menu items from the table can be found below.
Note: The display switches off automatically after about 10 seconds without any button being pushed. Push any
button to reactivate it.
Mode
DMX-mode
Color presets *
Automatic mode
Sound controlled mode
Program speed
Color intensity / Strobe
Brightness
Silent scene
Master/Slave mode

OPERATION

Display
7CH
5CH
Addr
4CH
3CH
2CH
Stat S01 – S16
Auto Au-1 – Au-2
Soun So-1 – So-2
SPEE Sp-1 – Sp-9
r0 – 255
g0 – 255
Colo
b0 – 255
SO – 255
diMM dl-1 – dl-9
OFF
SILE
ON
Slav Slav
24 • EN
Function
Setting DMX channel mode
DMX address setting
d 001 - d 506 7 - Channel DMX Mode
d 001 - d 508 5 - Channel DMX Mode
d 001 - d 509 4 - Channel DMX Mode
d 001 - d 510 3 - Channel DMX Mode
d 001 - d 511 2 - Channel DMX Mode
(Master - Mode)
2 internal programs; (Master - Mode)
2 internal programs; (Master - Mode)
Select the desired speed; (increasing)
Red (0 – 100 %)
Green (0 – 100 %)
Blue (0 – 100 %)
Strobe, increasing (0 – 20 Hz)
Brightness setting for programs in Automatic
mode, Sound controlled mode and with the
Color presets
Program continues automatically during
periods without music or bass - beat
Program stops / LEDs turn off
Slave mode
