Spot COB Bedienungsanleitung User Manual LED PARty Spot COB Kompakter Scheinwerfer mit DMX und einer 15-W-COB-LED in RGB Compact spotlight with DMX control and one 15 W COB LED in RGB STAND MASTER 33° STROBE ALONE SLAVE (optional) No. 42110201...
Produktbeschreibung Nun lass' die Party beginnen! Nur 0,5 kg schwer und locker mit einem Finger zu tragen - der LED PARty Spot COB ist wohl einer der kleinsten und vor allem leichtesten Stimmungsmachern unter den PAR-Spots! Ausgestattet mit einer 15-W-COB-LED in Rot, Grün und Blau liefert er für seine Dimensionen eine höchst erstaunliche Leistung ab und ist dabei erfreulich...
WICHTIGE SICHERHEITSHINWEISE WARNUNG! Lesen Sie aufmerksam die Sicherheitshinweise und benutzen Sie das Produkt nur wie in dieser Anleitung beschrieben, damit es nicht versehentlich zu Verletzungen oder Schäden kommt. Verwendungszweck • Bei diesem Gerät handelt es sich um einen Scheinwerfer, mit dem sich dekorative Lichteffekte erzeugen lassen. Es ist nur zur Dekoration und nicht für die Raumbeleuchtung in Haushalten geeignet.
Seite 6
Warnung vor Brand und Verletzungen • Halten Sie das Produkt vor leicht entflammbaren Materialien fern. Platzieren Sie es so, dass im Betrieb eine ausreichende Luftzirkulation gewährleistet ist. Das Gerät muss einen Mindestabstand von 50 cm zu angrenzenden Flächen haben und die Lüftungsöffnungen am Gehäuse dürfen auf keinen Fall abgedeckt werden. •...
INBETRIEBNAHME Montage Das Gerät lässt sich durch Ausklappen der Bügel auf dem Boden aufstellen oder über einen der Bügel an der Wand oder Decke montieren. Achten Sie darauf, dass Sie Schrauben und Dübel entsprechend der Wand- /Deckenbeschaffenheit und mit ausreichender Tragfähigkeit verwenden. Befestigen Sie das Gerät so, dass es nicht herunterfallen kann.
BEDIENUNG Nach dem Einschalten ist das Gerät betriebsbereit. Das Display zeigt die zuletzt eingestellte Betriebsart. Nehmen Sie nun die notwendigen Menüeinstellungen für die jeweilige Betriebsart mit den Bedientasten vor. Auch wenn Sie das Gerät ausschalten, bleiben alle Einstellungen gespeichert. Menüstruktur Die Wahl der Betriebsart erfolgt über das Display und die Bedientasten MENU, UP, DOWN und ENTER.
Seite 10
(*) Farbvoreinstellungen S 01 S 02 Grün S 03 Blau S 04 Gelb S 05 Magenta S 06 Cyan S 07 Dunkelorange S 08 Grüngelb S 09 Lachs S 10 Türkis S 11 Hellgrün S 12 Orange S 13 Lavendel S 14 Hellblau S 15...
STANDALONE-BETRIEB Statische Farben Im Farbmodus Farbvoreinstellungen strahlt das Gerät konstant in einer von 16 vorgegebenen Farben. Drücken Sie die Taste MENU so oft, bis das Display die Betriebsart Stat anzeigt. Wählen Sie die gewünschte Farbe von S01 – S16 (siehe Grafik) mit den Tasten UP bzw. DOWN aus. Bestätigen Sie mit der Taste ENTER. Automatikbetrieb In diesem Modus spielt das Gerät 2 verschiedene Effektprogramme automatisch ab.
FERNBEDIENUNG Mit der Fernbedienung lassen sich die integrierten Showprogramme im Automatikbetrieb oder im musikgesteuerten Betrieb anwählen sowie der Farbmodus mit vorgegebenen Farben. Die Fernbedienung funktioniert nur im Standalone-Betrieb, sie kann nicht im DMX- oder Slave-Betrieb verwendet werden. Durch mehrfaches Drücken der Tasten wird zwischen den Programmen umgeschaltet.
DMX-BETRIEB Anzahl der DMX-Kanäle und DMX-Startadresse einstellen Für den Betrieb über einen Controller mit DMX512-Protokoll verfügt das Gerät über 7 Steuerkanäle. Es kann aber auch in einen Modus mit 2, 3, 4 oder 5 Kanälen umgeschaltet werden, wenn andere Funktionen benötigt werden. Damit das Gerät vom Controller angesteuert werden kann, muss außerdem die DMX-Startadresse eingestellt werden.
Color change, dimmer and strobe are adjustable - and of course, there's also a sound control mode. www.eurolite.de The LED PARty Spot COB is perfectly suited for home use - for parties at home www.youtube.com/ as well as for kids' rooms.
IMPORTANT SAFETY INSTRUCTIONS WARNING! Please read the safety warnings carefully and only use the product as described in this manual to avoid accidental injury or damage. Intended use • This device is a spotlight for creating decorative lighting effects. It is only suitable for decoration and not for household lighting.
Seite 21
Caution – material damage • This device must not be connected to the mains voltage by means of a dimmer. • Lighting effects are not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. •...
OPERATING ELEMENTS AND CONNECTIONS (1) Fixation screw (2) Mounting brackets (3) Infrared sensor for the remote control (4) Lens/LED (5) DMX output (6) Power in (7) DMX input (8) USB port for QuickDMX receiver (9) LED display with operating buttons (10) Microphone 22 •...
SETUP Placing the unit The device may be placed on the floor by unfolding the brackets or mounted to the wall or ceiling via one of the brackets. Always choose screws and plugs which are suitable for use in your wall/ceiling and have enough holding power.
OPERATION After switching on, the device is ready for operation. The display indicates the last operating mode. The operating modes can be selected by means of the display and the control buttons. All settings remain stored even if the device is switching off. Menu structure The operating mode is set via the display and the buttons MENU, UP, DOWN and ENTER.
Seite 25
(*)Color presets S 01 S 02 Green S 03 Blue S 04 Yellow S 05 Magenta S 06 Cyan S 07 Dark orange S 08 Green yellow S 09 Salmon S 10 Turquoise S 11 Light green S 12 Orange S 13 Lavender S 14...
STAND-ALONE OPERATION Static colors In Color presets mode the device will constantly emit one of 16 preset colors. Press the MENU button so many times until Stat is indicated in the display. Use the UP and DOWN buttons to set the desired color S01 – S16 (see graphic).
REMOTE CONTROL The IR remote control allows convenient control of the integrated show programs in automatic mode or sound- controlled mode, and the color mode with preset colors. The IR remote control will only work in stand-alone mode, it will not work in DMX or slave mode Press the buttons repeatedly to switch between the programs. The display indicates the current setting.
DMX OPERATION Setting the number of DMX channels and the DMX starting address For operation with a controller with DMX512 protocol, the device is equipped with 7 control channels. However, it can also be switched to a mode with 2, 3, 4 or 5 channels if different functions are required. To be able to operate the device with a DMX controller, the DMX starting address must be set.
EUROLITE IR-16 Remote Control No. 51918203 EUROLITE TPC-10 Coupler, silver No. 59006856 EUROLITE Safety Bond UNV-5 3x600mm up to 5kg silver No. 58010372 EUROLITE DMX cable XLR 3pin 3m black No. 3022785H PSSO DMX cable XLR 3pin 3m black Neutrik No.
Seite 32
Eurolite is a brand of Steinigke Showtechnic GmbH · Andreas-Bauer-Str. 5 · 97297 Waldbüttelbrunn Germany D00140652.docx Version 1.0 Publ. 29/06/2022...
