Remote Control - EuroLite LED PARty Spot COB Bedienungsanleitung

The IR remote control allows convenient control of the integrated show programs in automatic mode or sound-
controlled mode, and the color mode with preset colors. The IR remote control will only work in stand-alone mode,
it will not work in DMX or slave mode Press the buttons repeatedly to switch between the programs. The display
indicates the current setting. When actuating a button, always hold the remote control in the direction of the sensor
at the control unit's front. A direct line of sight between the remote control and the sensor is required.
Battery
The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery
contacts prevents the battery from being discharged during storage. Prior to the first operation remove the foil from
the battery support on the rear side of the remote control. Otherwise operation of the remote control is not possible.
If the range of the remote control decreases, replace the battery. For this purpose, on the
rear side of the remote control press the small bar with the groove to the right and at the
same time remove the battery support. For operation, one 3 V button cell type CR 2025 is
required. When inserting, pay attention that the positive pole of the button cell shows
upwards in the support
* Preset colors:
0 Cyan
-- Warm white
1 Red
2 Green
3 Light blue
4 Orange
5
Blue
6 White
7 Lavender
8 Pink
9
Yellow

REMOTE CONTROL

Button
On/off
Automatic mode – auto programs
Sound-controlled mode – sound controlled programs
- Reduce speed of auto programs
- Reduce brightness - red, green and blue
- Increase speed of auto programs
- Increase brightness - red, green and blue
Pause on/off
Red
Green
Blue
Switching between "switches through auto programs" and "speed
adjustment of the auto programs"
Preset colors *
-
Red=000 / Green=255 / Blue=100
Red=255 / Green=255 / Blue=120
Red=255 / Green=000 / Blue=000
Red=000 / Green=255 / Blue=000
Red=000 / Green=255 / Blue=255
Red=255 / Green=122 / Blue=000
Red=000 / Green=000 / Blue=255
Red=255 / Green=255 / Blue=255
Red=122 / Green=000 / Blue=255
Red=255 / Green=000 / Blue=122
Red=255 / Green=255 / Blue=000
Function
27 • EN
Au-1, Au-2
SO-1, SO-2
