Static colors
In Color presets mode the device will constantly emit one of 16 preset colors. Press the MENU button so many
times until Stat is indicated in the display. Use the UP and DOWN buttons to set the desired color S01 – S16 (see
graphic). Confirm with the ENTER button.
Automatic mode
In this mode, 2 different effect programs can be called up. Press the MENU button so many times until Auto is
indicated in the display. Use the UP and DOWN buttons to set the desired program (Au-1 – Au-2). Confirm with the
ENTER button.
Sound controlled mode
In this mode, 2 different effect programs can be called up. Thereby the device will change the color to the rhythm of
the music (sufficient bass provided). Press the MENU button so many times until Soun is indicated in the display.
Use the UP and DOWN buttons to set the desired program (So-1 – So-2). Confirm with the ENTER button.
Speed
In this mode you can set the desired speed of the Auto and Sound programs. Press the MENU button so many
times until SPEE is indicated in the display. Use the UP and DOWN buttons to set the desired program speed (Sp-
1 – Sp-9). Confirm with the ENTER button.
Individual color mix
This mode allows the possibility of generating a mixed color by the intensity of the red, green and blue channels.
The device will constantly emit the color adjusted. Press the MENU button so many times until Colo is indicated in
the display. Confirm with the ENTER button.
Then use the buttons UP and DOWN to adjust the desired intensity of the basic colors: Red (r0 – 255), Green (g0 –
255) and Blue (b0 – 255). Confirm with the ENTER button for each color.
Strobe effect
In addition, you can set the desired flash speed under the Colo mode. Press the MENU button repeatedly until the
display shows the Colo mode. Confirm with the ENTER button. Under this menu item you can set the flash speed
with the UP or DOWN buttons (S0 = slow, S255 = fast). Confirm the speed selection with the ENTER button.
Brightness
In this mode, you can set the desired brightness setting for programs in automatic mode, sound controlled mode
and color presets. Press the MENU button repeatedly until the display shows diMM mode. Select the desired
brightness (dl-1 - dl-9) with the UP or DOWN buttons. Confirm with the ENTER button.
Several devices may be interconnected (max. 32). Then all slave units can be synchronized and controlled with the
master unit without the need for a DMX controller. The devices must be set to the corresponding operating modes.
1
Configure all slave units before connecting the master unit. Press the MENU button so many times until SLAV
is indicated in the display. Confirm with the ENTER button.
2
Connect the DMX output of the master unit to the DMX input of the first slave unit. Then connect the DMX
output of the first slave unit to the DMX input of the second slave unit, etc. until all units have been connected in
a chain. Make sure the master unit is the first in the chain. Do not connect a DMX controller to the DMX input of
the master unit.
3
Set the master unit to the desired operating mode (see Master Mode under Menu structure). The
interconnected devices will now operate synchronously.
STAND-ALONE OPERATION
MASTER/SLAVE OPERATION
26 • EN
