EEx / I.S. approval:
KEMA 04ATEX1316X ..................................
Applicable for zone ..................................... 0, 1, 2, 20, 21 or 22
FM approval:
Max. ambient temperature for T6 ............... 60°C
Applicable in ................................................ Cl. I, Div. 2, Gr. A,B,C,D
Applicable for .............................................. Cl. I, Div. 1, Gr. A,B,C,D
Entity, FM Installation Drawing No .............. 5116QF01
Observed authority requirements:
EMC 2004/108/EC
Emission and immunity ....................... EN 61326
LVD 73/23/EEC ............................................ EN 61010-1
PELV/SELV ................................................... IEC 364-4-41 and EN 60742
ATEX 94/9/EC .............................................. EN 50014, EN 50020, EN 50284
FM, ASCN ................................................... 3600, 3610, 3611, 3810
UL, Standard for Safety .............................. UL 508
36 36
II (1) GD
[EEx ia] IIC
Cl. I, Zone 2, Gr. IIC, IIB, IIA
Cl. II, Div. 1 Gr. E, F, G
Class III, Division 1
Cl. I, Zone 0/1, Gr. IIC, IIB, IIA
Class II, Zone 20 and 21
Standard:
EN 61241-0 and IEC 61241-11
INSTRUCTIONS FOR INTRINSICALLY SAFE
INSTALLATION OF 5116B
The intrinsically safe circuits are galvanically connected to the communications
interface unit. The communications interface may only be connected tempo-
rarily, under the condition that the intrinsically safe circuits are disconnected.
When a higher ingress protection than IP20 is required, this has to be achieved
by an additional enclosure which is suitable for the applicable environmental
conditions.
When two or more units are placed next to each other it has to be assured that
the terminations for the intrinsically safe circuits are all on the same side and
are separated from the non-intrinsically safe circuits of the units which could
be mounted above or below it.
Each combination of circuits (to terminations 44, 43, 42, 41 or to terminations
53, 52, 51 or to terminations 54, 53, 52, 51) shall be connected via separated
cables or if the combinations are in one cable shall be type A or B in accor-
dance with EN 60079-14 Clause 12.2.2.8.
Year of manufacture can be taken from the first two digits in the serial number.
