• A red symbol is displayed in the window indicating
operational readiness.
• Press the red Test button. This action simulates a
leakage current.
• If the machine is working properly, the circuit-break-
er will disconnect the load from the mains. This is
displayed in the window through the disappearance
of the red symbol.
• Protection of man and animal is effective only if the
machine works properly.
• The Reset button must be pressed a second time
for operation.
• The load can now be inserted.
Technical data:
Triggering leakage current:
Power supply:
Load capacity:
Number of pins:
Preliminary fuse:
Protection type:
Dimensions:
USE ACCORDING TO MANUFACTURER'S
INSTRUCTIONS!
The portable leakage current circuit-breaker is de-
signed for wet grinding machines and similar elec-
trical loads in the household.
It is simply connected between the mains power sup-
ply and the load, and therefore offers optimum pro-
tection against physical contact with live components
and sudden restart of the machine after restoration
of power.
Always operate the machine with the provided leak-
age current circuit-breaker installed.

12. Cleaning

Caution! Pull out power plug.
Clean the machine after each work cycle.

13. Transport

Attention! Pull out the power plug
To transport the machine, position the machine head
to the front and use the adjustment stops to fix it in
place.

14. Storage

Store the device and its accessories in a dark, dry
and frost-proof place that is inaccessible to children.
The optimum storage temperature is between 5 and
30˚C.
Store the electrical tool in its original packaging.
Cover the electrical tool in order to protect it from
dust and moisture. Store the operating manual with
the electrical tool.
26 | GB
< 30 mA
230 V~/50 Hz
16A (3680 W)
2-pin wired
16 A
IP54
126 x 50 x 88 mm
www.scheppach.com

15. Maintenance

Caution! Pull out power plug.
• Replace worn out cutting discs.
• Replace damaged protection device
• Dust and pollution must be removed regularly from
the machine. The best way to clean the machine is
with a piece of cloth or brush.
• All moveable parts must be re-lubricated at period-
ic intervals.
• Do not use any corrosive substances to clean the
plastic. A damp cloth is sufficient in most cases.
• The tub (4) and coolant pump (13) must be cleaned
regularly to remove dirt, as otherwise the pump or
the pipe or the cooling of the diamond cutting disc
(10) is not guaranteed.
Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: cutting wheel, carbon brush, table & cut-
ting head guides
* Not necessarily included in the scope of delivery!
Spare parts
Please quote the following in your order for spare
parts:
• Type of device
• Article No. of device
• Ident. No. of device
• Spare Part No. of the required spare part

16. Disposal and recycling

The equipment is supplied in packaging to
prevent it from being damaged in transit. The
raw materials in this packaging can be re-
used or recycled. The equipment and its ac-
cessories are made of various types of
material, such as metal and plastic. Defec-
tive components must be disposed of as special
waste. Ask your dealer or your local council.
Old devices must not be disposed of with house-
hold waste!
This symbol indicates that this product must
not be disposed of together with domestic
waste in compliance with the Directive
(2012/19/EU) pertaining to waste electrical and
electronic equipment (WEEE). This product must be
disposed of at a designated collection point. This can
occur, for example, by handing it in at an authorised
collecting point for the recycling of waste electrical
and electronic equipment.
