6.4 Displaying the last error message

Figure 13
System menu selection
Figure 14
Special menu selection
Figure 15
Last error message selection
From the initial display press the MENU button four times so that you see the following display.
VOLUME SYSTEM
KEY1 KEY2
Press T2 to select the system menu. The following display appears.
SPECIAL INSTALL
KEY1 KEY2
Press T1. The following display appears.
LAST ERROR CLR ALL
KEY1 KEY2
Press T1 to see the last error message.
Press T1 repeatedly to display all error messages in turn. The error messages are stored according to a
first in, first out principle. Up to 99 error messages can be stored.
Press the RESET button repeatedly to return to the initial menu.
