5. Installation

Figure 5

Displaying the system menu

Figure 6

Install menu selection

Ensure all components are connected and switched on. From the initial display press the MENU button

four times so that you see the following display.

VOLUME

SYSTEM

KEY1

KEY2

Note: When the display shows KEY 1 or K1 it is referring to button T1; KEY2 or K2 refers to button T2.

To select the System menu press T2. The following display appears.

SPECIAL

INSTALL

KEY1

KEY2

Press T2 to select the Install menu. FeVac

same time the INSTALL function is actuated for all FeVac Two systems connected to the FeVac One.

During this process, the following displays appear in turn on a fully equipped FeVac One:

Alarm Switch 1 . . . Alarm Switch 8

Emergency Mic 1

Emergency Mic 2

External input

UPS - system1

Alarm start switch

Alarm module

Alert module

FeVac Two system 1

Press the RESET button repeatedly to return to the initial menu.

One now tests all components connected to it, while at the

(up to 16)

Installed
