Manual Settings

6.3 Status / version monitoring

Figure 11
Status/version menu display
Figure 12
Status/version selection
16
From the initial display press the MENU button once so that you see the following display.
MONITOR STATUS/VER
KEY1 KEY2
Press T2 to see the Status/version menu. The following display appears.
STATUS VERSION
KEY1 KEY2
Press T2 to see the hard- and software-version number.
Press T1 to see the system status. Repeatedly pressing T1 displays the status of all installed components
in turn.
Press the RESET button to return the display to the initial menu.
