5.

Approvals

(Approvals are valid for marked devices)
Construction
PY X-L-15-CPR: 01CPR2018-01-02
Product
Rated voltage
Regulation
(CPR)
Voltage range in accordance with
(
305/2011/EU)
EN54-23
Lens colours
17
0786
Signalling area
In preparation
Environmental protection class
Installation position
22
The test was performed using the supplied diaphragm nipple and the outer mounting
0843
bores.
PY X-L-15-CPR: G217100
Data see Construction Product Regulation (305/2011/EU). Lens colour: red, clear
VdS
PY X-L-15-CPR: G218006,
Lens colours: White, yellow, amber, green, blue. These lens colors are not certified ac-
cording to EN54-23 and are not to be used for alerting in case of fire.
PYRA Xenon beacons PY X-S-05 comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules.
6.

Commissioning

6.1

Safety information

DANGER - Danger to life due to electric shock
Voltage-carrying devices and exposed connection cables may cause electric shocks and serious
accidents.
➢ Only trained and authorized electricians may work on electrical connections.
➢ Disconnect all supply lines from mains before installation and secure them against reconnec-
tion. Always ensure absence of voltage.
➢ Wait for the discharge phase of 5 minutes for the electrical components. The device should
only be opened afterwards.
➢ The operating voltage must only be applied when the housing is firmly closed.
WARNING - Danger due to unauthorized use of the devices
Improper use may lead to serious accidents.
➢ Ensure that the connection cable is protected against pulling and twisting during installation.
The devices are only intended for fixed installation.
DANGER - Danger due to damage to the devices
Non-compliance with the information on the type plate can lead to serious accidents.
➢ Always observe the information on the type plate when installing and maintaining the devices.
CAUTION - Risk of injury due to sharp edges or heated components
➢ Wear gloves during any installation, assembly or service/maintenance work.
➢ Perform wiring tasks at a distance from sharp edges, corners and internal components.
CAUTION - Impairment of vision
➢
Avoid constant, direct glances into the activated lights to prevent impairment of vision.
05/2022
Operating instructions
19.2 – 28.8 V DC
0.5 Hz,
EN 54-23 Category O:
see document 30396-005-1
see document 30396-005-1
Page 3 / 6
PY X-L-15-CPR
24 V DC
red and clear
0.75 Hz, 1 Hz
Type B
086200005
