6.2

Electrical connection

➢ Observe the
Safety
The electrical connection is established on the connection board in the lower part.
Operating voltage
connection
All terminals are duplicated. This allows for simple through branch wiring.
Note:
Devices with DC voltage are equipped with reverse polarity protection. No function if the polarity of the connec-
tions is reversed.
Connecting cables:
6.3

Positioning of the resistor (1kOhm) for line monitoring

➢ Always mount the resistor for line monitoring in the last device.
➢ Remove any resistors that are not required.
6.4

Setting the flash frequency

The flash frequency is set using the S1 switch on the board in the lens, see table below.
Note: Depending on the adjusted flash frequency the appearance of the first flash after switching on may take
up to 10 s.
Synchronization:
The devices comply with the requirements of EN54-23 (synchronous operation).
S1
05/2022
information.
AC:
DC:
Operating instructions
1 Hz 0,75 Hz
*
* Factory setting
Page 5 / 6
PY X-L-15-CPR
0,5 Hz 0,1 Hz
