Technische Daten
12
Kommunikationsprotokoll PROFINET IO-Controller
12
Technische Daten
12.1
Kommunikationsprotokoll PROFINET IO-Controller
54
Handbuch – MOVI-C
Parameter
Maximale Anzahl PROFINET
IO‑Devices/AR (Appliaction Relati-
on)
Maximale Anzahl PROFINET
IO‑Devices/AR in Abhängigkeit
vom Sendetakt
Sendetakt
Maximale Anzahl zyklischer Ein-
gangsdaten
Maximale Anzahl zyklischer Aus-
gangsdaten
Maximale Anzahl zyklischer Ein-
gangsdaten pro IO-Device
Maximale Anzahl zyklischer Aus-
gangsdaten pro IO-Device
Maximale Anzahl Submodule
Maximale Datenanzahl für azykli-
sches Lesen/Schreiben (Record-
Zugriff)
Alarmbehandlung
Diagnose Daten
DCP-Funktionen über API
(DCP = Discovery and Configurati-
on Protocol)
(API = Application Programming In-
terface)
Unterstützte Protokolle
Funktionen
®
CONTROLLER progressive UHX65A-M
Beschreibung
•
128 (RT)
•
64 (IRT)
•
maximal 16 AR bei Sendetakt 1 ms
•
maximal 64 AR bei Sendetakt 2 ms
•
RT-Modus: 1 ms, 2 ms, 4 ms
•
IRT-Modus: 1 ms, 2 ms, 4 ms
5652 Bytes (inklusive IOxS Statusbytes)
5760 Bytes (inklusive IOxS Statusbytes)
1440 Bytes (inklusive IOxS Statusbytes)
1440 Bytes (inklusive IOxS Statusbytes)
2048
65535
wird unterstützt mithilfe des IEC-Anwenderpro-
gramms
200 Byte Puffer pro IO-Device
•
DCP SET NameofStation (Namenszuwei-
sung des IO-Device)
•
DCP SET IP (IP-Parameter des IO-Devices
setzen)
•
DCP SET SIGNAL (Signal IO-Device)
•
DCP Reset FactorySettings (Reset IO-Devi-
ce auf Werkseinstellung)
•
DCP IDENTIFY (Bus scan)
•
DCP GET (Datensatz des IO-Device abfra-
gen)
•
RTC - Real Time Cyclic Protocol, Klasse 1
•
RTA - Real Time Acyclic Protocol
•
DCP - Discovery and configuration Protocol
•
CL-RPC - Connectionless Remote Procedu-
re Call
•
Fast Startup von PROFINET IO-Devices
wird unterstützt.
•
MRP Client (Medienredundanz Teilnehmer)
