6. DMX protocol

The P8 offers 3 different channel modes. In the menu area PERSONALITY -> DMX MODE you
can select your mode. The used mode will be displayed in the main menu.
Mode 1 (M1)
Channel 1 Pan
Channel 2 Pan fine
Channel 3 Tilt
Channel 4 Tilt fine
Channel 5 Control
Channel 6 Shutter
Channel 7 Dimmer
Channel 8 Iris
Channel 9 Focus
Channel 10 Gobo 1
Channel 11 Gobo 1 rotation
Channel 12 Gobo 2
Channel 13 Gobo 2 rotation
Channel 14 Prism
Channel 15 Prism rotation
Channel 16 CTC 3200K
Channel 17 Fixed colors
Channel 18 Pan/Tilt speed
Channel 19 Effect speed
Channel 20 Blackout move
Channel 21 Animation wheel
Channel 22 Animation wheel rotation Blackout move
Channel 23 Frost
Channel 24 Zoom
Channel 25 Red
Channel 26 Green
Channel 27 Blue
Channel 28
Channel 29
Channel 30
Channel 31
Channel 32
Mode 2 (M2)
Pan
Pan fine
Tilt
Tilt fine
Control
Shutter
Dimmer
Iris
Focus
Gobo 1
Gobo 1 rotation
Gobo 1 rotation fine
Gobo 2
Gobo 2 rotation
Gobo 2 rotation fine
Prism
Prism rotation
CTC 3200K
Fixed colors
PAN/Tilt speed
Effect speed
Animation wheel
Animation wheel rotation Green
Frost
Zoom
Red
Red fine
Green
Green fine
Blue
Blue fine
Mode 3 (M3)
Pan
Pan fine
Tilt
Tilt fine
Control
Shutter
Dimmer
Iris
Focus
Gobo 1
Gobo 1 rotation
Gobo 2
Gobo 2 rotation
Prism
Prism rotation
CTC 3200K
Fixed colors
Blackout move
Animation wheel
Animation wheel rotation
Frost
Zoom
Red
Blue
P8
- 39 -
