dormakaba Mounting instructions
4.5

Glass to glass mounting

4.5.1

Mount the side panel

ATTENTION
Risk of damage to the glass door leaf by
inadequate, unstable mounting
The side panel must be attached with
sufficient load-bearing capacity. A simple
silicone seam for the floor attachment is
insufficient! Use dormakaba wall connection
profile or dormakaba U-profile!
dormakaba recommends using the dormakaba wall
connection profile item no.: 07.050/051/052
(Fig. 27/2). The floor mounting can alternatively be
done with the dormaka U-profile item no.: 07.093
(Fig. 27/1).
1. Check the side panel for damage, e.g. conchoidal
fractures and/or damaged edges. Do not install a
damaged side panel.
2. Mount the side panel according to the enclosed
mounting instructions.
2
Fig. 27 Installing the side panel
4.5.2

Check glass door leaf and side panel

CAUTION
Risk of injury from broken glass Cutting/
cutting off the fingers on sharp parts of
broken glass.
Wear protective gloves.
1. Check glass door leaves for damage,
e.g. glass for conchoidal fractures and/or
damaged edges. Do not install damaged glass
door leaves.
2. Check dimensions of glass preparation (Fig. 13).
TENSOR
4.5.3
1.
2. Select the appropriate gaskets (Fig. 28/2)
3. Peel off the protective film of the adhesive tape
Fig. 28
4. Fix the gasket onto the base- and counter-plate.
5. Tighten the marked screws. The tightening torque
1
Fig. 29
4.5.4
Clean glass surfaces around the clamping plates. Use
commercial glass cleaner. Do not use thinners!
WN 059361 45532

Prepare the double-action hinge

Disassemble the counter-plates (Fig. 28/1).
according to glass thickness (see Chapter 4.2).
on the base- and counter-plate.
3.
1
1.
1.
Preparing the double-action hinge
should be 5 Nm.
5 Nm
Tighten the marked screws with torque.

Clean glass surfaces

Installation
2
2.
1
3.
2020-09 21
