dormakaba Mounting instructions
4.4

Frame with embedded mounting plate

4.4.1

Check the glass door leaf

CAUTION
Risk of injury from broken glass
Cutting/cutting off the fingers on sharp
parts of broken glass.
Wear protective gloves.
1. Check the glass door leaf for damage,
e.g. conchoidal fractures and/or damaged edges.
Do not install damaged glass door leaves.
2. Check dimensions of glass preparation (Fig. 10).
4.4.2

Preparing the door frame

1. Vertically mark the recesses for the mounting
plates in the door frame. For dimensions A and B
see Fig. 10.
2. Cut out 4 mm deep recesses for the mounting
plate in the door frame.
Fig. 21 Dimensional drawing for mounting plates' recesses in
the door frame
TENSOR
4.4.3
1.
2. Select the appropriate gaskets (Fig. 22/2)
3. Peel off the protective film of the adhesive tape
Fig. 22
4. Fix the gasket onto the base- and counter-plate.
5. Tighten the marked screws. The tightening torque
Fig. 23
WN 059361 45532

Prepare the double-action hinge

Unscrew the counter-plate (Fig. 22/1).
according to the glass thickness (see Chapter 4.2).
on the base- and counter-plate (Fig. 22/1 and
Fig. 22/3).
3.
2
2.
1
1.
Preparing the double-action hinge
should be 5 Nm.
5 Nm
Tighten the marked screws with torque.
Installation
3
2020-09 19
