Installing the OPT/i TPS SpeedNet connector on the
power source
Requirement The „4-fold switch" option must be installed in the power source.
Preparing to in-
1
stall
2
6
3
Connect the supplied cable harness to the print
SCRATSW
Installation at the
1
1
front side of the
housing
Fold out the control panel
12
All manuals and user guides at all-guides.com
Turn off power source and disconnect from mains
Take off the right side panel
1
3
2
3
1
2
2
2
Remove the blanking cover below the control panel
(push from the inside outwards)
