Fronius OPT/i TPS SpeedNet Connector Installationsanleitung Seite 14

Installation at the
1
1
back side of the
housing
Select blanking cover (1,2 or 3) to remove.
Figure shows possible mounting plate (4).
3
3
Insert socket correctly into the free opening
4
4
* *
Install socket and connection plate
14
All manuals and user guides at all-guides.com
5
2
1
4
3
* *
3
* *
1
* *
2
* *
5
* *
7
1
2
2
4
(1)
(2)
3
(3)
(4)
Remove the selected blanking cover (push from the in-
side outwards)
5
5
* *
6
* *
4
*
Place cover
2
TOP
1
