Fronius OPT/i TPS SpeedNet Connector Installationsanleitung Seite 17

All manuals and user guides at all-guides.com
4
X10 X11 X12 X13
7
6
Fit the cover cap
4
Connect the black cable to the PC
X14
5
board / X14
5
Connect the 4-pin cable to the PC
6
board
Secure the cables with cable ties
7
17
