All manuals and user guides at all-guides.com
/ Perfect Charging /
Perfect Welding
OPT/i WF R Drahtende-Ringsensor
OPT/i WF R wire end ring sensor
42,0410,2088
/ Solar Energy
004-26022018
Installationsanleitung
Ersatzteilliste
Systemerweiterung
Installations instructions
Spare parts list
System extension

Werbung

Kapitel

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Fronius OPT/i WF R

  • Seite 1 All manuals and user guides at all-guides.com / Perfect Charging / Perfect Welding / Solar Energy Installationsanleitung OPT/i WF R Drahtende-Ringsensor Ersatzteilliste Systemerweiterung Installations instructions OPT/i WF R wire end ring sensor Spare parts list System extension 42,0410,2088 004-26022018...
  • Seite 2 All manuals and user guides at all-guides.com...
  • Seite 3: Inhaltsverzeichnis

    Sensor auf ein Drahtfass montieren ..................... Sensor auf eine Großspule montieren ....................Sensor auf die Drahtfass-Aufnahme WF MOUNTING Drum montieren..........Sensor anschließen ..........................OPT/i WF R Drahtende-Ringsensor einstellen ..................Funktionsweise des Schalters "Delay" ....................Appendix Spare parts list: OPT/i WF R Drahtende-Ringsensor ................
  • Seite 4 All manuals and user guides at all-guides.com...
  • Seite 5: Allgemeines

    Sensor mit Halterung Verbindungskabel dieses Dokument (nicht abgebil- det) Voraussetzungen HINWEIS! OPT/i WF R Drahtende-Ringsensor kann nur verwendet werden, wenn OPT/i Ext. Sensorstecker in dem verwendeten Drahtvorschub / der verwen- deten SplitBox eingebaut ist. Anschlussbele- Anschlussbelegung des Steckers vom Verbindungskabel:...
  • Seite 6 All manuals and user guides at all-guides.com Anschlussbelegung des Sensors: BN (braun) BU (blau) BK (schwarz)
  • Seite 7: Opt/I Wf R Drahtende-Ringsensor Montieren

    All manuals and user guides at all-guides.com OPT/i WF R Drahtende-Ringsensor montieren Sicherheit WARNUNG! Fehlbedienung und fehlerhaft durchgeführte Arbeiten können schwerwiegende Personen- und Sachschäden verursachen. Alle in diesem Dokument beschriebenen Arbeiten und Funktionen dürfen nur von geschultem Fachpersonal ausgeführt werden, wenn folgende Dokumente voll- ständig gelesen und verstanden wurden:...
  • Seite 8: Sensor Auf Ein Drahtfass Montieren

    All manuals and user guides at all-guides.com Sensor auf ein HINWEIS! Um einen störungsfreien Betrieb zu gewährleisten, dürfen sich in un- Drahtfass montie- mittelbarer Nähe des Sensors außer der zu detektierenden Drahtelektrode keine metallischen Gegenstände befinden. Draht-Führungsseele aus Stahl: Draht-Führungsseele aus Kunststoff:...
  • Seite 9: Sensor Auf Eine Großspule Montieren

    All manuals and user guides at all-guides.com Sensor auf eine HINWEIS! Um einen störungsfreien Betrieb zu gewährleisten, dürfen in unmittel- Großspule mon- barer Nähe des Sensors außer der zu detektierenden Drahtelektrode keine me- tieren tallischen Gegenstände angebracht sein. Draht-Führungsseele aus Stahl: Draht-Führungsseele aus Kunststoff:...
  • Seite 10: Sensor Auf Die Drahtfass-Aufnahme Wf Mounting Drum Montieren

    All manuals and user guides at all-guides.com Sensor auf die Drahtfass-Auf- nahme WF MOUNTING Drum montieren Halterung (1) vom Sensor abmontieren Distanzstück aus dem Lieferumfang der Drahtfass- Aufnahme an der Unterseite der Drahtfass-Aufnahme ansetzen 2 x TX25 M5 x 12 mm Sensor wie abgebildet auf das Distanzstück aufsetzen Sensor mit 2 Schrauben TX25 M5 x 12 mm aus dem Lieferumfang der Drahtfass-Aufnahme fixieren...
  • Seite 11: Sensor Anschließen

    Stecker (1) vom Verbindungskabel an einen Anschluss OPT/i Ext. Sensorste- cker (2) des Drahtvorschubes / der SplitBox anschließen Stecker (4) an den Sensor anschließen OPT/i WF R Draht- Verwendete Drahtelektrode in der Öff- ende-Ringsensor nung (1) des Sensors während des ge- einstellen...
  • Seite 12 All manuals and user guides at all-guides.com...
  • Seite 13 General ..............................Scope of supply ............................ Prerequisites ............................Pin assignments............................ Fitting the OPT/i WF R wire end ring sensor ..................... Safety..............................Fitting the sensor to a wire drum......................Fitting the sensor to a large spool......................Fitting the sensor to the WF MOUNTING Drum holder ................
  • Seite 14 All manuals and user guides at all-guides.com...
  • Seite 15: General

    Connecting cable This document (not shown) Prerequisites NOTE! The OPT/i WF R wire end ring sensor can only be used if an OPT/i ext. sensor plug has been installed in the respective wirefeeder or SplitBox. Pin assignments Pin assignment of connecting cable plug:...
  • Seite 16 All manuals and user guides at all-guides.com Pin assignment of sensor: BN = brown BU = blue BK = black...
  • Seite 17: Fitting The Opt/I Wf R Wire End Ring Sensor

    All manuals and user guides at all-guides.com Fitting the OPT/i WF R wire end ring sensor Safety WARNING! Incorrect operation or shoddy workmanship can cause serious injury or damage. All functions described in this document may only be carried out by trained and...
  • Seite 18: Fitting The Sensor To A Wire Drum

    All manuals and user guides at all-guides.com Fitting the sensor NOTE! To ensure trouble-free operation, ensure that there are no metal objects, to a wire drum apart from the wire electrode being monitored, in the immediate vicinity of the sen- sor.
  • Seite 19: Fitting The Sensor To A Large Spool

    All manuals and user guides at all-guides.com Fitting the sensor NOTE! To ensure trouble-free operation, no metal objects, apart from the wire to a large spool electrode being monitored, may be fitted in the immediate vicinity of the sensor. Steel inner liner: Plastic inner liner:...
  • Seite 20: Fitting The Sensor To The Wf Mounting Drum Holder

    All manuals and user guides at all-guides.com Fitting the sensor to the WF MOUNTING Drum holder Remove the holder (1) from the sensor Attach the spacer supplied with the wire drum holder to the underside of the wire drum holder 2 x TX25 M5 x 12 mm Place the sensor on the spacer as shown...
  • Seite 21: Connecting The Sensor

    Connect the plug (4) to the sensor Adjusting the Rotate the wire electrode in the OPT/i WF R wire opening (1) of the sensor during the end ring sensor entire adjustment process LED (3) lights up when the sensor...
  • Seite 22: Operation Of The "Delay" Switch

    All manuals and user guides at all-guides.com Operation of the The sensor outputs a signal when it detects "Delay" switch the end of the wire. If the sensor then de- tects the wire electrode again, the signal re- mains on for a short period. The amount of time the signal remains on depends on the setting of the "Delay"...
  • Seite 23: Appendix

    All manuals and user guides at all-guides.com Appendix...
  • Seite 24: Spare Parts List: Opt/I Wf R Drahtende-Ringsensor

    All manuals and user guides at all-guides.com Spare parts list: OPT/i WF R Drahtende-Ringsensor...
  • Seite 25 All manuals and user guides at all-guides.com...
  • Seite 26 All manuals and user guides at all-guides.com...
  • Seite 27 All manuals and user guides at all-guides.com...
  • Seite 28 All manuals and user guides at all-guides.com FRONIUS INTERNATIONAL GMBH Froniusplatz 1, A-4600 Wels, Austria Tel: +43 (0)7242 241-0, Fax: +43 (0)7242 241-3940 E-Mail: sales@fronius.com www.fronius.com www.fronius.com/addresses Under http://www.fronius.com/addresses you will find all addresses of our Sales & service partners and Locations...
